4 Point Markers
7.
Tap the 4 Point Markers soft key. A soft key menu for the 4 markers method appears.
1
Marker
2
Marker
1
Sets marker
Places marker at the
cursor position
1
Sets marker
Places marker at the
cursor position
2
2
Return loss
Splice loss
Set marker Y2.
Places marker Y2 at the
cursor position
Sets marker
Places marker at the
cursor position
3
3
Marker Y2
3
Marker
Press to set all
markers together.
See “2 Point Markers
(when the marker
mode is Marker)”
Note
• Set the markers in the order shown above, starting with the measurement start point (the distance
reference).
• The measured loss value differs depending on the specified approximation method.
• Set the correct position for
2
. The splice loss changes greatly depending on the position of
2
.
6.1 Operating Cursors and Markers
