Report Format
If the file action is set to File Report, you can select the number of waveforms to display in a page. If
you select 2Trace, you can select the export order, sort order, and event list items.
Number of Waveforms to Display (Report Format)
1Trace: The waveform information of a single file is included in a single page.
2Trace: The waveform information of two files is included in a single page.
Sort By
Select the file export order when exporting multiple selected files to PDF.
File Name: Files are exported to PDF in order by the file name string.
Date: Files are exported to PDF in order by date.
ID: Files are exported to PDF in order by ID number.
ID Position
Set where in the file name the ID (ID number) of the selected file is located.* Files with ID numbers
set to positions other than top or bottom cannot be exported to PDF in the correct order.
* For the file name format, see “Filename Setup Screen” in section 6.3.
Top: The four digit number in the beginning of the file name is identified as the ID number.
Bottom: The four digit number in the end of the file name is identified as the ID number.
Sort Order
A -> Z: In the case of numbers, the order is 0 to 9. In the case of alphabet characters, the order
is a to z.
Z -> A: In the case of numbers, the order is 9 to 0. In the case of alphabet characters, the order
is z to a.
EventList Setup
Set the items to show in the event list. If the number waveforms the display (report format) is
2Trace, up to five items can be displayed in the event list. If five items are On, other items cannot
be set to On.
ON: Events are displayed in the event list.
OFF: Events are not displayed in the event list.
Setting Labels
You can specify the following items. If you save waveform data measured from an optical pulse to a
file in SOR format, the following label information is also saved.
Item Description
Company Name Up to 36 characters
Name Up to 36 characters
Cable ID Up to 36 characters
Fiber ID Up to 36 characters
Fiber type 652:Conventional SMF General purpose single mode
653:Dispersion Shifted SMF Dispersion shifted
654:Cut-Off Shifted SMF Cut-off shifted
655:Non-Zero Dispersion Shifted SMF Non-zero, dispersion shifted, single mode
656:NZDSF for Wideband Transport Wideband non-zero, dispersion shifted, single
mode
657:Bend Optimized SMF Bend optimized single mode
651:Multi-Mode Fiber Multi mode
Cable Code Up to 36 characters
Originating Loc (A) Up to 36 characters
Terminating Loc (B) Up to 36 characters
Current Data Flag Shows the operation state.
BUILT (BC), REPAIRED (RC), OTHER (OT), and CURRENT (CC)
