YOKOGAWA CQ1 User Manual

<5. Functions of CQ1 Software> 5-49
IM 80J01A01-01E
󳏄 Edit
Edit selected node setting.
i. Append
Select the reference Object Detect Setting from the list to be
shown.
ii. OK
Close window after confirming changes.
iii. Cancel
Cancel changes and close window.
i. Append
Select a reference Object Detect Setting from the list to be
shown.
ii. Link Condition
Select link condition. Please refer to 󳔛Conditions of Sub
Nodes in (7) Link Setting (page 5-46).
iii. OK
Close window after confirming changes.
iv. Cancel
Cancel changes and close window.
i
iii
ii
i
v
iv
iii
ii
