YOKOGAWA CQ1 User Manual

<3. Name of Each Part/Starting and Shutting Down the Equipment> 3-5
IM 80J01A01-01E
(8) Breaker
For the Utility Box
(9) Power Cable Connector
Port to connect power cable
(10) Maintenance Connector
Not in use
(11) Remote Interlock Connector
Port to connect lase interlock connector
(12) Reserved Connector
Not in use
(13) CQ1 Main Unit Power Cable Connector
Port to connect power cable
(14) Fiber Port
Port to insert the fiber to Utility Box
(9)
(8)
(10)
(11)
(12)
(13)
(14)
