Make button to status (white) and select well in “WellTable”.
Acquired images and result of recognition are displayed in
“ImageViewer”.
Make button to status (green), check number of Thumbnail
Chart to display and select wells in “WellTable”. Scattergrams or
histograms are displayed in “ThumbnailChart”.
For details of each window, refer to following
“WellTables” -> 5.6.5 WellTable Window
“ImageViewer” -> 5.6.2 ImageViewer Window
ThumbnailChart” -> 5.6.4 ThumbnailChart Window
