4.8 Starting and Stopping Waveform Acquisition
Starting and Stopping Waveform Acquisition.
Press START/STOP to start or stop waveform acquisition.
The key is illuminated while the DL850E/DL850EV is acquiring waveforms.
Waveform Acquisition and Indicators
• When the START/STOP key is illuminated, the DL850E/DL850EV is acquiring waveforms. “Running”
appears in the lower left of the screen.
• When the START/STOP key is not illuminated, waveform acquisition is stopped. “Stopped” appears
in the lower left of the screen.
DL850E/DL850EV Operation When the Acquisition Mode Is Set to
Averaging
• Averaging stops when you stop waveform acquisition.
• If you restart waveform acquisition again, averaging starts from the beginning.
START and STOP Operations during Accumulation
• Accumulation stops when you stop acquisition.
• If you restart waveform acquisition, past waveforms are cleared, and accumulation starts over.
Note
You can use the snapshot feature to retain the displayed waveform on the screen. This feature allows you to
retain a waveform on the screen while the DL850E/DL850EV continues signal acquisition.
