6-16
IM DL850E-03EN
6.11 Computer Interface
USB-PC Connection
Item Specifications
Connector type USB type B receptacle
Electrical and mechanical
specifications
USB Rev. 2.0 compliant
Supported transfer mode HS (High Speed; 480 Mbps) and FS (Full Speed; 12 Mbps)
Number of ports 1
Supported protocols Functions as a device that conforms to one of the following two protocols.
USBTMC-USB488 (USB Test and Measurement Class Ver. 1.0)
*
GP-IB commands can be used through USB.
Mass Storage Class Ver.1.1
Only reading from a PC to the internal hard disk of the DL850E/DL850EV is possible.
(Operations, such as writing, deleting and formatting, are impossible.)
PC system requirements A PC with a USB port, running the English or Japanese version of Windows 7 (32 bit), Windows
Vista (32 bit), or Windows XP (32 bit, SP2 or later)
* A separate driver is required.
Ethernet
Item Specifications
Connector type RJ-45 modular jack
Ports 1
Electrical and mechanical
specifications
IEEE802.3
Transmission system Ethernet (1000BASE-T, 100BASE-TX, 10BASE-T)
Communication protocol TCP/IP
Supported services DHCP, DNS, SNTP client, SMTP client, FTP server and client, LPR, Web server, and VXI11
GP-IB (/C1 or /C20 option)
Item Specifications
Connector type 24-pin connector
Electrical specifications Complies with IEEE St’d 488-1978 (JIS C 1901-1987)
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, and C0
Protocol IEEE St’d 488.2-1992
Code ISO (ASCII)
Mode Addressable mode
Address Talker and listener addresses can be specified from 0 to 30.
Remote mode release Remote mode can be cleared with the SHIFT+CLEAR TRACE key (except during Local Lockout).
