6.3 Time Axis
Item Specifications
Selectable time scale range The display of minutes per div, hours per div, and days per div is also possible.
100 ns/div
1
to 1 s/div (in 1-2-5 steps), 2 s/div, 3 s/div, 4 s/div, 5 s/div, 6 s/div, 8 s/div, 10 s/div, 20 s/div,
30 s/div, 1 min/div to 10 min/div (in 1 min steps), 12 min/div, 15 min/div, 30 min/div, 1 h/div to 10 h/div
(in 1 h steps), 12 h/div, 1 day/div, 2 days/div, 3 days/div, 4 days/div, 5 days/div, 6 days/div, 8 days/div,
10 days/div, 20 days/div
Time accuracy
2
±0.005%
External clock input Connector type: BNC
Input level: TTL level
Detected edge: Rising
Frequency range: Up to 9.5 MHz
Minimum pulse width: 50 ns or more for both High and Low
1 1 μs/div when the High-Speed 100 MS/s, 12-Bit Isolation Module (720210 or 720211) is not installed
2 Under standard operating conditions after the warm-up time has passed
6.4 Display
Item Specifications
Display 10.4-inch TFT LCD
Display screen size 210.4 mm × 157.8 mm
Display resolution
*
1024 × 768 (XGA)
Resolution of the waveform
display
801 × 656 (normal) or 1001 × 656 (wide)
Display format Divisions: Up to three screen divisions can be displayed at the same time.
Each division can contain one of the following windows: TY, ZOOM1, ZOOM2, XY1,
XY2, FFT1, or FFT2.
* The LCD may include a few defective pixels (within 5 ppm over the total number of pixels including RGB). The LCD may
contain some pixels that are always illuminated or that never light. Please be aware that these are not defects.
