App-28

IM DL850E-03EN

DL850E/DL850EV USB Keyboard

m (CH key) + ENTER (CH key) M when NUM LOCK is illuminated on the DL850E/DL850EV

1 (CH key) 1 when NUM LOCK is illuminated on the DL850E/DL850EV

2 (CH key) 2 when NUM LOCK is illuminated on the DL850E/DL850EV

3 (CH key) 3 when NUM LOCK is illuminated on the DL850E/DL850EV

4 (CH key) 4 when NUM LOCK is illuminated on the DL850E/DL850EV

5 (CH key) 5 when NUM LOCK is illuminated on the DL850E/DL850EV

6 (CH key) 6 when NUM LOCK is illuminated on the DL850E/DL850EV

7 (CH key) 7 when NUM LOCK is illuminated on the DL850E/DL850EV

8 (CH key) 8 when NUM LOCK is illuminated on the DL850E/DL850EV

9 (CH key) 9 when NUM LOCK is illuminated on the DL850E/DL850EV

0 (CH key) 0 when NUM LOCK is illuminated on the DL850E/DL850EV

ENTER (CH key) ENTER when NUM LOCK is illuminated on the DL850E/DL850EV

. (CH key) . when NUM LOCK is illuminated on the DL850E/DL850EV

– (CH key) – when NUM LOCK is illuminated on the DL850E/DL850EV

ESC ESC or F8

Select soft key 1 F1

Select soft key 2 F2

Select soft key 3 F3

Select soft key 4 F4

Select soft key 5 F5

Select soft key 6 F6

Select soft key 7 F7

SNAPSHOT PAUSE

Turn ZOOM MAG to the right INSERT

Turn VERTICAL SCALE to the right HOME

Turn HORIZONTAL TIME/DIV to the right PAGE UP

Turn ZOOM MAG to the left DELETE

Turn VERTICAL SCALE to the left End

Turn HORIZONTAL TIME/DIV to the left PageDown

Right arrow →

Left arrow ←

Up arrow ↑

Down arrow ↓

Appendix 5 USB Keyboard Key Assignments
