5-4
IM 710105-17E
5.1 List of Commands
Command Function Page
:ANALysis:PANalyze<x>:SWLoss:SC
ALe:MODE
Sets or queries the scaling mode. 5-68
:ANALysis:PANalyze<x>:SWLoss:SC
ALe:SENSitivity
Sets or queries the span from the center value for manual scaling. 5-68
:ANALysis:PANalyze<x>:SWLoss:TR
ANge (Time Range)
Sets or queries the measurement time period. 5-68
:ANALysis:PANalyze<x>:SWLoss:UL
EVel
Sets or queries the voltage level used to determine the loss calculation
period for total loss computation.
5-69
:ANALysis:PANalyze<x>:SWLoss:UN
IT
Sets or queries the power unit. 5-69
:ANALysis:PANalyze<x>:SWLoss:V
CE
Sets or queries the collector-emitter saturation voltage value for total loss
computation.
5-69
:ANALysis:PANalyze<x>:TYPE
Sets or queries the type of power supply analysis. 5-69
:ANALysis:PMEAsure<x>?
Queries all power measurement settings. 5-69
:ANALysis:PMEAsure<x>:IDPRoxim
al?
Queries all distal, mesial, and proximal settings. 5-69
:ANALysis:PMEAsure<x>:IDPRoxima
l:MODE
Sets or queries the distal, mesial, and proximal point mode setting. 5-69
:ANALysis:PMEAsure<x>:IDPRoxima
l:PERCent
Sets or queries the distal, mesial, and proximal points as percentages. 5-69
:ANALysis:PMEAsure<x>:IDPRoxima
l:UNIT
Sets or queries the distal, mesial, and proximal points as voltages. 5-70
:ANALysis:PMEAsure<x>:IMEThod
Sets or queries the high and low points. 5-70
:ANALysis:PMEAsure<x>:INDicator
Sets or queries the measurement location indicator. 5-70
:ANALysis:PMEAsure<x>:MEASure?
Queries all the settings for automated measurement of power measurement
parameters.
5-70
:ANALysis:PMEAsure<x>:MEASure:<
Parameter>?
Queries the setting of a power measurement parameter. 5-70
:ANALysis:PMEAsure<x>:MEASure:<
Parameter>:COUNt?
Queries the normal statistical processing count of the power measurement
parameter.
5-70
:ANALysis:PMEAsure<x>:MEASure:<
Parameter>:{MAXimum|MEAN|MINimu
m|SDEViation}?
Queries a statistical value of a power measurement parameter. 5-70
:ANALysis:PMEAsure<x>:MEASure:<
Parameter>:STATe
Queries the on/off status of the power measurement parameter. 5-71
:ANALysis:PMEAsure<x>:MEASure:<
Parameter>:VALue?
Queries an automatically measured value of a power measurement
parameter.
5-71
:ANALysis:PMEAsure<x>:MEASure:A
LL
Collectively turns on or off the power measurement parameter. 5-71
:ANALysis:PMEAsure<x>:MODE
Sets or queries the on/off status of power measurement. 5-71
:ANALysis:PMEAsure<x>:RANGe
Sets or queries the measurement source window. 5-71
:ANALysis:PMEAsure<x>:SETup?
Queries all power measurement input settings. 5-71
:ANALysis:PMEAsure<x>:SETup:ADE
Skew
Executes auto deskewing for power measurement. 5-71
:ANALysis:PMEAsure<x>:SETup:I?
Queries all current input channel settings for power measurement. 5-71
:ANALysis:PMEAsure<x>:SETup:I:D
ESKew
Set or queries auto deskewing of the current input channel for power
measurement.
5-71
:ANALysis:PMEAsure<x>:SETup:I:P
ROBe
Queries all current-to-voltage conversion ratio settings of the probe
connected to the current input channel for power measurement.
5-72
:ANALysis:PMEAsure<x>:SETup:RTR
ace
Sets or queries the deskewing source trace for power measurement. 5-72
:ANALysis:PMEAsure<x>:SETup:U?
Queries all voltage input channel settings for power measurement. 5-72
:ANALysis:PMEAsure<x>:SETup:U:D
ESKew
Set or queries auto deskewing of the voltage input channel for power
measurement.
5-72
:ANALysis:PMEAsure<x>:SETup:U:P
ROBe
Queries all voltage-to-voltage conversion ratio settings of the probe
connected to the voltage input channel for power measurement.
5-72
:ANALysis:PMEAsure<x>:TRANge
Sets or queries the measurement time period. 5-72
:ANALysis:PMEAsure<x>:UDPRoxim
al?
Queries all distal, mesial, and proximal settings. 5-72
:ANALysis:PMEAsure<x>:UDPRoxima
l:MODE
Sets or queries the distal, mesial, and proximal point mode setting. 5-72
:ANALysis:PMEAsure<x>:UDPRoxima
l:PERCent
Sets or queries the distal, mesial, and proximal points as percentages. 5-73
