5.1 List of Commands
Command Function Page
:TRIGger[:ATRigger]:PSI5:SETup:
DATA:EDETection
Sets or queries the error detection method for PSI5 signal triggering. 5-272
:TRIGger[:ATRigger]:PSI5:SETup:
DATA:SOURce
Sets or queries the data source for PSI5 signal triggering. 5-272
:TRIGger[:ATRigger]:PSI5:SETup:
SYNC
Sets or queries the sync signal for PSI5 signal triggering. 5-272
:TRIGger[:ATRigger]:PULSe?
Queries all pulse width trigger settings. 5-272
:TRIGger[:ATRigger]:PULSe:POLar
ity
Sets or queries the pulse width trigger source polarity. 5-272
:TRIGger[:ATRigger]:PULSe:SOUR
ce
Sets or queries the pulse width trigger source. 5-272
:TRIGger[:ATRigger]:SENT?
Queries all SENT signal trigger settings. 5-272
:TRIGger[:ATRigger]:SENT:CTICk
Sets or queries the SENT signal trigger clock tick value. 5-272
:TRIGger[:ATRigger]:SENT:FLENg
th
Sets or queries the SENT signal trigger frame length (clock ticks). 5-272
:TRIGger[:ATRigger]:SENT:PPULse
Sets or queries the presence or absence of pause pulses for SENT signal
triggering.
5-273
:TRIGger[:ATRigger]:SENT:SOURce
Sets or queries the SENT signal trigger source. 5-273
:TRIGger[:ATRigger]:SENT:VERSi
on
Sets or queries the SENT signal analysis specification version. 5-273
:TRIGger[:ATRigger]:TV?
Queries all TV trigger settings. 5-273
:TRIGger[:ATRigger]:TV:FIELd
Sets or queries the field where TV triggering will be used. 5-273
:TRIGger[:ATRigger]:TV:FRAMe
Sets or queries the frame skip feature for TV triggering. 5-273
:TRIGger[:ATRigger]:TV:{HDTV|NT
SC|PAL|SDTV|USERdefine}?
Queries all TV trigger mode settings. 5-273
:TRIGger[:ATRigger]:TV:{HDTV|NT
SC|PAL|SDTV|USERdefine}:LINE
Sets or queries the line where TV triggering will be used. 5-273
:TRIGger[:ATRigger]:TV:{HDTV|NT
SC|PAL|SDTV|USERdefine}:POLari
ty
Sets or queries the TV trigger input polarity. 5-273
:TRIGger[:ATRigger]:TV:LEVel
Sets or queries the TV trigger level. 5-273
:TRIGger[:ATRigger]:TV:LFORmat
Sets or queries the format for specifying the line where TV triggering will be
used.
5-274
:TRIGger[:ATRigger]:TV:SOURce
Sets or queries the TV trigger source. 5-274
:TRIGger[:ATRigger]:TV:TYPE
Sets or queries the TV trigger input type. 5-274
:TRIGger[:ATRigger]:TV:USERdefi
ne?
Queries all user-defined TV trigger settings. 5-274
:TRIGger[:ATRigger]:TV:USERdefi
ne:DEFinition
Sets or queries the user-defined TV trigger definition setting. 5-274
:TRIGger[:ATRigger]:TV:
USERdefine:HFRejection
(HighFrequencyREJECTION)
Sets or queries the low-pass filter (HF rejection) setting for user-defined TV
triggering.
5-274
:TRIGger[:ATRigger]:TV:USERdefi
ne:HSYNc(Hsync Freq)
Sets or queries the horizontal sync frequency for user-defined TV triggering. 5-274
:TRIGger[:ATRigger]:TV:USERdefi
ne:LINE
Sets or queries the user-defined TV trigger line number. 5-274
:TRIGger[:ATRigger]:TV:USERdefi
ne:POLarity
Sets or queries the user-defined TV trigger input polarity. 5-275
:TRIGger[:ATRigger]:TV:USERdefi
ne:SGUard
Sets or queries the user-defined TV trigger sync guard setting. 5-275
:TRIGger[:ATRigger]:WIDTh?
Queries all state width trigger settings. 5-275
:TRIGger[:ATRigger]:WIDTh:BITS?
Queries all logic input settings for state width triggering. 5-275
:TRIGger[:ATRigger]:WIDTh:BITS:
HEXa
Sets the logic input state for state width triggering in hexadecimal notation. 5-275
:TRIGger[:ATRigger]:WIDTh:BITS:
PATTern
Sets or queries the logic input state pattern for state width triggering. 5-275
:TRIGger[:ATRigger]:WIDTh:CHANn
el<x>
Sets or queries the trigger condition of a channel for state width triggering. 5-275
:TRIGger[:ATRigger]:WIDTh:CLO
Ck?
Queries all clock signal settings for state width triggering. 5-275
:TRIGger[:ATRigger]:WIDTh:CLOCk
:POLarity
Sets or queries the clock signal polarity for state width triggering. 5-275
