5.1 List of Commands
Command Function Page
:TRIGger[:ATRigger]:WIDTh:CLOCk
:SOURce
Sets or queries the clock signal for state width triggering. 5-276
:TRIGger[:ATRigger]:WIDTh:CONDi
tion
Sets or queries the trigger condition for state width triggering. 5-276
:TRIGger[:ATRigger]:WIDTh:LOGic
Sets or queries the combination condition for state width triggering. 5-276
:TRIGger[:ATRigger]:WIDTh:TIME
<x>
Sets or queries the pulse width setting for state width triggering. 5-276
:TRIGger[:ATRigger]:WIDTh:TYPE
Sets or queries the time width mode for state width triggering. 5-276
:TRIGger:COMBination
Sets or queries the trigger combination. 5-276
:TRIGger:DELay?
Queries all delay settings. 5-276
:TRIGger:DELay:TIME
Sets or queries the delay (the time between the trigger point and the trigger
position).
5-276
:TRIGger:HOLDoff?
Queries all hold-off settings. 5-276
:TRIGger:HOLDoff:TIME
Sets or queries the hold-off time. 5-276
:TRIGger:MODE
Sets or queries the trigger mode. 5-277
:TRIGger:POSition
Sets or queries the trigger position. 5-277
:TRIGger:SCOunt
Sets or queries the number of times the trigger condition must be met when
the trigger mode is set to Single(N).
5-277
:TRIGger:SOURce?
Queries all trigger source settings for enhanced triggering. 5-277
:TRIGger:SOURce:CHANnel<x>?
Queries all of the settings of the specified trigger source for enhanced
triggering.
5-277
:TRIGger:SOURce:CHANnel<x>:COUP
ling
Sets or queries the specified trigger source trigger coupling for enhanced
triggering.
5-277
:TRIGger:SOURce:CHANnel<x>:HFRe
jection (HighFrequencyREJECTION)
Sets or queries the low-pass filter setting of the specified trigger source for
enhanced triggering.
5-277
:TRIGger:SOURce:CHANnel<x>:HYST
eresis
Sets or queries the noise rejection setting of the specified trigger source for
enhanced triggering.
5-277
:TRIGger:SOURce:CHANnel<x>:LEV
el
Sets or queries the trigger level of the specified trigger source for enhanced
triggering.
5-277
:TRIGger:SOURce:CHANnel<x>:WID
Th
Sets or queries the window width of the specified trigger source for enhanced
triggering.
5-278
:TRIGger:SOURce:CHANnel<x>:WIND
ow
Sets or queries the window on/off status of the specified trigger source for
enhanced triggering.
5-278
WAVeform Group
:WAVeform?
Queries all information about waveform data. 5-279
:WAVeform:ALL?
Queries all settings related to the :WAVeform:ALL:SEND? query. 5-279
:WAVeform:ALL:SEND?
Queries the waveform data specified by the :WAVeform:ALL:TRACe
command.
5-279
:WAVeform:ALL:TRACe
Sets or queries the waveform that is the target of the :WAVeform:ALL:SEND?
query.
5-280
:WAVeform:BITS?
Queries the bit length of the waveform data specified by the
:WAVeform:TRACe
command.
5-280
:WAVeform:BYTeorder
Sets or queries the transmission byte order for waveform data in word format
that is 2 bytes or longer in length.
5-280
:WAVeform:END
Sets or queries which point will be used as the last data value for the
waveform specified by
:WAVeform:TRACe
.
5-280
:WAVeform:FORMat
Sets or queries the format of the waveform data to be sent. 5-280
:WAVeform:LENGth?
Queries the total number of data points of the waveform data specified by
the
:WAVeform:TRACe
command.
5-280
:WAVeform:OFFSet?
Queries the offset value used to convert the waveform data specified by the
:WAVeform:TRACe
command to physical values.
5-280
:WAVeform:POSition?
Queries the vertical position that is used to convert waveform data to voltage
when :WAVeform:FORMat is set to RBYTe.
5-280
:WAVeform:RANGe?
Queries the range used to convert the waveform data specified by the
:WAVeform:TRACe
command to physical values.
5-280
:WAVeform:RECord
Sets or queries the record number that WAVeform commands will be applied
to.
5-280
:WAVeform:RECord? MINimum
Queries the minimum record number of the source channel. 5-281
:WAVeform:SEND?
Queries the waveform data specified by the
:WAVeform:TRACe
command. 5-281
:WAVeform:SIGN?
Queries whether or not signs are included in the binary data of the source
waveform specified by
:WAVeform:TRACe
when the data is queried.
5-281
