104
IM FG410-01EN
4. BASIC OPERATION
Set the following items as needed.
• Marker amplitude [Marker] (2nd page of setting screen)
p.96
• Stop level [StpLvl] (3rd page of setting screen)
p.93
This setting can be used only for gated single-shot sweep.
• External control with multi-I/O connector [ExtCtrl] (3rd page of setting screen)
p.98
• Oscillation stop unit for gated single sweep [OscStop] (3rd page of setting screen)
p.93
This setting can be used only for gated single-shot sweep.
• Sync output [SyncOut] (3rd page of setting screen)
p.96
To Next Page
