CAUTION
 IfadifferenceinpotentialexistsbetweenthegroundsoftheBNC
connectors,donotshortcircuittheseBNCconnectorgrounds,asthis
maydamagetheequipment.
ATTENTION
 Encasdedifférencedepotentielentrelesterresetlesconnecteurs
BNC,nemettezpasencourt-circuitcesterresdeconnecteursBNC:
vousrisqueriezd’endommagerl’appareil.
 CautionsonFloatingGroundConnectionforFG410
ANALOG
CKT
1MΩ
1MΩ
FCTN OUT
SYNC/SUB OUT
MOD/ADD IN
Housing ground
10MHz
REF IN
EXT
REF
CKT
Use with potential
difference of 42 Vpk or
less.
Housing ground
Use with potential
difference of 42 Vpk or
less.
Use with potential
difference of 42 Vpk or
less.
Figure 3-6. Cautions on Floating Ground Connection for FG410
3.3 Cautions on Floating Ground Connection
