7 SPECIFICATIONS
7.6 ModulatedOscillationMode
7.6.1 General
Modulation type FM, FSK, PM, PSK, AM, DC offset modulation, PWM
Modulation source Internal, external (selectable)
Internal modulation waveform
Other than FSK, PSK Sine wave, square wave (50% duty), triangular wave (50%
symmetry), rising ramp wave, falling ramp wave, noise, arbitrary
wave
FSK, PSK Square wave (50% duty)
Internal modulation frequency
Other than FSK, PSK 0.1 mHz to 100 kHz (5 digits or 0.1 mHz resolution)
FSK. PSK 0.1 mHz to 1 MHz (5 digits or 0.1 mHz resolution)
Internal modulation sync output
Output waveform Square wave with 50% duty that rises at zero phase position of
internal modulation waveform
Fixed to low level while internal modulation waveform is noise
Output connector Shared with sync/sub-output connector
Internal modulation signal output
Output voltage
-
3 V to +3 V/open
Output connector Shared with sync/sub-output connector
External modulation input (other than FSK, PSK)
Input voltage range ±1 V full scale
Maximum allowed input ±2 V
Input impedance 10 kΩ , unbalanced
Input frequency DC to 25 kHz
Input connector Front panel (FG410) / rear panel (FG420)
BNC receptacle
Shared with external addition input, cannot be used simultaneously
with adding operation
External modulation input (FSK, PSK)
Polarity Positive, negative (selectable)
Input frequency DC to 1 MHz
Input connector Use of external trigger input.
Input voltage and input impedance follow the external trigger input
specifications.
