YOKOGAWA FG420 User Manual

109
IM FG410-01EN
4.9 BurstSettingandManipulation
4.9.1 Burstoscillationtypes
The following four types of burst oscillation can be done.
• Auto burst
Oscillation and stop are automatically repeated with the respectively specified wave number. No
trigger signal is required.

p.110
• Trigger burst
Oscillation with the specified wave number is done each time a trigger is received.

p.113
• Gate oscillation
Oscillation is done in integer cycles or half cycles while the gate is on.

p.117
• Triggered gate oscillation
This is gate oscillation that switches the gate on/off each time a trigger is received.

p.122
4.9 Burst Setting and Manipulation
