YOKOGAWA FG420 User Manual

6
IM FG410-01EN
2.PREPARATIONS BEFORE USE
AVERTISSEMENT
Cet appareil contient des pièces sous haute tension. N'ouvrez jamais
le couvercle. Toute inspection interne de cet appareil doit être effectuée
exclusivement par des techniciens de service qualifiés par Yokogawa
Test & Measurement Corporation.
c) Repacking
When repacking this equipment for transportation, etc., use a shipping carton of sufficient strength
and capacity to safely accommodate the equipment and hold its weight.
d) Options
The following options are available and can be purchased separately.
Model/partsnumber Product Description
705928 Multi input/output cable For sweep/sequence control
751537-E2 Rack mount kit Inch rack mounting (for 1 unit)
751537-J2 Rack mount kit Millimeter rack mounting (for 1 unit)
751538-E2 Rack mount kit Inch rack mounting (for 2 units)
751538-J2 Rack mount kit Millimeter rack mounting (for 2 units)
• Multi-I/O cable
This cable is used when using the multi-I/O connector on the rear panel.
A 2 meter multi-core shielded cable is connected to the mini-Dsub 15-pin connector. Since the
opposite side is cut off, process that side according to the connection destination.
For the connector's pin assignment and cable differentiation,

p. 20 .
• Rack mount adapters
These adapters are for mounting the equipment on a 19-inch IEC, EIA standard rack, or JIS
standard rack.
Each type of adapter is available as a 1-unit and 2-unit model (for side-by-side mounting), for a
total lineup of 4 models.
2.2 Installation
CAUTION
Operating Environment Limitations
This product is a Class A (for industrial environments) product.
Operation of this product in a residential area may cause radio
interference in which case the user will be required to correct the
interference.
ATTENTION
Limitations relatives à l'environnement opérationnel
Ce produit est un produit de classe A (pour environnements industriels).
L'utilisation de ce produit dans un zone résidentielle peut entraîner une
interférence radio que l'utilisateur sera tenu de rectifier.
