5
IM FG410-01EN
• Configurationandaccessory check
The accessories of this product are listed below. Check that there are no missing items and no flaws
are found.
Main unit ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
Instruction Manual (Basics IM FG410-01EN) ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧ 1
Inquiries (PIM 113-01Z2) ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
FG410/FG420 Arbitrary / Function Generator (IM FG410-92Z1) ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
Safety Instruction Manual (IM 00C01C01-01Z1) ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧ 1
CD (PDF instruction manuals, application software) ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
PDF instruction manuals:
Arbitrary & Function Generator User's Manual(Application).pdf
IM FG410-02EN
Communication Interface User's Manual.pdf IM FG410-17EN
ARBITRARY WAVEFORM EDITOR User's Manual.pdf
IM FG410-61EN
SEQUENCE EDIT SOFTWARE User's Manual.pdf IM FG410-62EN
LabVIEW Driver SOFTWARE User's Manual.pdf IM FG410-63EN
Transferring and Outputting DLMDLSL Series Waveform Data.pdf IM FG410-64EN
Application software:
Arbitrary Waveform Editing Software, Sequence Editing Software,
LabVIEW Driver
Power cord set (2 m, with 3-prong plug) ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧ 1
Suffix Part No. SpecificationsandNotes
-D A1006WD UL, CSA, and PSE standard
-F A1009WD VDE standard
-Q A1054WD BS standard
-R A1024WD AS standard
-H A1064WD GB standard
-N A1088WD NBR standard
-T A1100WD Taiwanese standard
-B A1101WD Indian standard
-U A1102WD IEC Plug Type B
Make sure that the attached power cord meets the designated standards of the country and area
that you are using it in. If the suffix code is -Y, a power cord is not included.
• DoNotDamagethePowerCord
Nothing should be placed on top of the power cord, and it should be kept away from any heat sources.
When removing the plug from the power outlet, do not pull on the cord. Pull from the plug. If the
power cord is damaged or if you are using the instrument in a location where the power supply
specifications are different, purchase a power cord that matches the specifications of the region that
the instrument will be used in.
WARNING
This product contains high-voltage parts. Never remove the cover.
All internal inspections of this product are to be performed only by
service technicians qualified by Yokogawa Test & Measurement
Corporation.
2.1 Checking Before Use
