YOKOGAWA FG420 User Manual

40
IM FG410-01EN
4. BASIC OPERATION
4.3.5 Changingthedisplayunit
a) Changingtheprefix(unitprefix:k,m,M,etc.)
Frequency is used as an example below. The amplitude and pulse width can be changed in a similar
manner.
1.
Select frequency and then press the
ENTER key to open the input field.
ENTER
2.
Press the [Prefix] soft key and the
cursor will move to before “Hz”.
The right arrow key can also be used
to move the cursor to before “Hz”.
3.
Change the unit to MHz, kHz, Hz, mHz, or uHz with the
up/down arrow keys or the modify knob. Even when the
display unit and decimal point position are changed, the
value of the setting itself remains unchanged.
kHz display MHz display
The input field
opens.
The cursor
moves to
before “Hz”
when [Prefix] is
pressed.
Unit change
or
