YOKOGAWA FG420 User Manual

75
IM FG410-01EN
Modulation source [Source]
Either an internal or external modulation source can be selected.

p.76
Internal modulation waveform [ModFctn]
This is the internal modulation source waveform. Sine, square, triangular, rising ramp, falling
ramp, noise, and arbitrary can be chosen from.

p.76
Internal modulation frequency [ModFreq]
This is the frequency of the internal modulation source.

p.76
Sync output [SyncOut]
This is the output signal from the sync/sub-output terminal. Waveform basic phase sync, internal
modulation sync, and internal modulation waveform can be chosen from.

p.78
4.7 Modulation Setting and Manipulation
