1-86
IM 04L51B01-01EN
Only the following types of data that are checked in the table below can be used in TLOG,
CLOG, and PRE.
Data
Comp. Type
I/O
channel
Math
channel
Communication
channel
Constant,
variable
constant
Internal
switch
Flag Recording
status
Integer
data
TLOG
   
TLOG.PSUM

1
CLOG
  
PRE
   
Other computations
       
Bad examples: TLOG.SUM(S01), CLOG.AVE(0001.0002.K01), PRE(S01)
1 Only applies to pulse input module channels.
Decimal Place
Set the decimal place for span lower and span upper.
SpanLower,Span Upper
Set the measurement range.
The decimal place is determined by the Decimal place setting.
Unit
Set the unit of computed values.
TLOG
Setup Item Selectable Range or Options Default Value
Timer type Timer, Match Time Timer Timer
Timer No. 1, 2, 3, 4, 5
1
, 6
1
, 7
1
, 8
1
, 9
1
, 10
1
, 11
1
, 12
1
1
Sum scale Off, sec, min, hour Off
Reset Off, On Off
1 Release number 3 and later
Timer type
Set the timer type.
Timer No.
Set the number of the timer that you want to use.
Sum scale
Set the sum scale depending on the unit of measured values.
Set the sum scale when using sum computation (TLOG.SUM).
Example: If the unit of the measured value is “m
3
/min,” select min.
If you select Off, the measured data is summed as-is once per scan interval.
1.8ConfiguringMathChannels(/MToption)
