1-15
IM 04L51B01-01EN
Configuring the GX/GP and Viewing the Settings
1
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-66
Setting display colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
Enabling the partial expanded display →page 1-40
→page 1-114
Displaying the color scale band (band area (in, out), color)
→page 1-66
Displaying alarm point marks (mark kind, alarm mark color)
ConfiguringAnalogOutputChannels(Settingmenu:AOchannelsettings)
Source module: Analog output module (GX90YA)
Setting the Range
Item Reference
Setting the range (type, range, span lower, span upper)
→page 1-70
Setting the reference channel (channel type, CH number)
Setting preset values
Setting preset actions (at power on, on error, during stop conditions)
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-74
Setting display colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
ConfiguringDigitalOutputChannels(Settingmenu:DOchannelsettings)
Source module: Digital output module (GX90YD)
Digital input/output module (GX90WD)
Setting the Range
Item Reference
Setting the range (type, span lower, span upper, unit)
→page 1-76
Setting the action (energize/de-energize, action (and, or, reflash), hold, relay action
on ACK)
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-80
Setting Display Colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
Displaying on/off (1/0) states with characters
WhatDoYouWanttoConfigure?
To Next Page
