YOKOGAWA GX20 User Manual

4-23
IM 04L51B01-01EN
Using Modbus Functions (Communicating with Modbus devices)
1
2
3
4
5
App
Index
Unit I/O Channel Data Input Register Data Type
Expandable I/O 5 Lower bytes of the channel 5001 data 331001 32-bit floating point
Higher bytes of the channel 5001 data 331002
| |
Lower bytes of the channel 5050 data 331099
Higher bytes of the channel 5050 data 331100
Lower bytes of the channel 5101 data 331101
Higher bytes of the channel 5101 data 331102
| |
Lower bytes of the channel 5150 data 331199
Higher bytes of the channel 5150 data 331200
Lower bytes of the channel 5201 data 331201
Higher bytes of the channel 5201 data 331202
| |
Lower bytes of the channel 5250 data 331299
Higher bytes of the channel 5250 data 331300
Lower bytes of the channel 5301 data 331301
Higher bytes of the channel 5301 data 331302
| |
Lower bytes of the channel 5350 data 331399
Higher bytes of the channel 5350 data 331400
Lower bytes of the channel 5401 data 331401
Higher bytes of the channel 5401 data 331402
| |
Lower bytes of the channel 5450 data 331499
Higher bytes of the channel 5450 data 331500
Lower bytes of the channel 5501 data 331501
Higher bytes of the channel 5501 data 331502
| |
Lower bytes of the channel 5550 data 331599
Higher bytes of the channel 5550 data 331600
Expandable I/O 6 Lower bytes of the channel 6001 data 336001
Higher bytes of the channel 6001 data 336002
| |
Lower bytes of the channel 6050 data 336099
Higher bytes of the channel 6050 data 336100
Lower bytes of the channel 6101 data 336101
Higher bytes of the channel 6101 data 336102
| |
Lower bytes of the channel 6150 data 336199
Higher bytes of the channel 6150 data 336200
Lower bytes of the channel 6201 data 336201
Higher bytes of the channel 6201 data 336202
| |
Lower bytes of the channel 6250 data 336299
Higher bytes of the channel 6250 data 336300
Lower bytes of the channel 6301 data 336301
Higher bytes of the channel 6301 data 336302
| |
Lower bytes of the channel 6350 data 336399
Higher bytes of the channel 6350 data 336400
Lower bytes of the channel 6401 data 336401
Higher bytes of the channel 6401 data 336402
| |
Lower bytes of the channel 6450 data 336499
Higher bytes of the channel 6450 data 336500
Lower bytes of the channel 6501 data 336501
Higher bytes of the channel 6501 data 336502
| |
Lower bytes of the channel 6550 data 336599
Higher bytes of the channel 6550 data 336600
4.5 Modbus Function and Register Assignments
