4-24
IM 04L51B01-01EN
• 16-bitSignedInteger
Unit I/O Channel Data Input Register Data Type
GX/GP main unit Channel 0001 data 302001 16-bit signed integer
| |
Channel 0050 data 302050
Channel 0101 data 302051
| |
Channel 0150 data 302100
Channel 0201 data 302101
| |
Channel 0250 data 302150
Channel 0301 data 302151
| |
Channel 0350 data 302200
Channel 0401 data 302201
| |
Channel 0450 data 302250
Channel 0501 data 302251
| |
Channel 0550 data 302300
Channel 0601 data 302301
| |
Channel 0650 data 302350
Channel 0701 data 302351
| |
Channel 0750 data 302400
Channel 0801 data 302401
| |
Channel 0850 data 302450
Channel 0901 data 302451
| |
Channel 0950 data 302500
Expandable I/O 1 Channel 1001 data 312001
| |
Channel 1050 data 312050
Channel 1101 data 312051
| |
Channel 1150 data 312100
Channel 1201 data 312101
| |
Channel 1250 data 312150
Channel 1301 data 312151
| |
Channel 1350 data 312200
Channel 1401 data 312201
| |
Channel 1450 data 312250
Channel 1501 data 312251
| |
Channel 1550 data 312300
Expandable I/O 2 Channel 2001 data 317001
| |
Channel 2050 data 317050
Channel 2101 data 317051
| |
Channel 2150 data 317100
Channel 2201 data 317101
| |
Channel 2250 data 317150
Channel 2301 data 317151
| |
Channel 2350 data 317200
Channel 2401 data 317201
| |
Channel 2450 data 317250
Continued on next page
4.5 Modbus Function and Register Assignments
