4-26
IM 04L51B01-01EN
Unit I/O Channel Data Input Register Data Type
Expandable I/O 6 Channel 6001 data 337001 16-bit signed integer
| |
Channel 6050 data 337050
Channel 6101 data 337051
| |
Channel 6150 data 337100
Channel 6201 data 337101
| |
Channel 6250 data 337150
Channel 6301 data 337151
| |
Channel 6350 data 337200
Channel 6401 data 337201
| |
Channel 6450 data 337250
Channel 6501 data 337251
| |
Channel 6550 data 337300
I/O Channel Data Status Information
Unit I/O Channel Data Input Register Data Type
GX/GP main unit Channel 0001 status information 302501 16-bit signed integer
| |
Channel 0050 status information 302550
Channel 0101 status information 302551
| |
Channel 0150 status information 302600
Channel 0201 status information 302601
| |
Channel 0250 status information 302650
Channel 0301 status information 302651
| |
Channel 0350 status information 302700
Channel 0401 status information 302701
| |
Channel 0450 status information 302750
Channel 0501 status information 302751
| |
Channel 0550 status information 302800
Channel 0601 status information 302801
| |
Channel 0650 status information 302850
Channel 0701 status information 302851
| |
Channel 0750 status information 302900
Channel 0801 status information 302901
| |
Channel 0850 status information 302950
Channel 0901 status information 302951
| |
Channel 0950 status information 303000
Expandable I/O 1 Channel 1001 status information 312501
| |
Channel 1050 status information 312550
Channel 1101 status information 312551
| |
Channel 1150 status information 312600
Channel 1201 status information 312601
| |
Channel 1250 status information 312650
Channel 1301 status information 312651
| |
Channel 1350 status information 312700
Channel 1401 status information 312701
| |
Channel 1450 status information 312750
Continued on next page
4.5 Modbus Function and Register Assignments
