YOKOGAWA GX20 User Manual

4-27
IM 04L51B01-01EN
Using Modbus Functions (Communicating with Modbus devices)
1
2
3
4
5
App
Index
Unit I/O Channel Data Input Register Data Type
Expandable I/O 1 Channel 1501 status information 312751 16-bit signed integer
| |
Channel 1550 status information 312800
Expandable I/O 2 Channel 2001 status information 317501
| |
Channel 2050 status information 317550
Channel 2101 status information 317551
| |
Channel 2150 status information 317600
Channel 2201 status information 317601
| |
Channel 2250 status information 317650
Channel 2301 status information 317651
| |
Channel 2350 status information 317700
Channel 2401 status information 317701
| |
Channel 2450 status information 317750
Channel 2501 status information 317751
| |
Channel 2550 status information 317800
Expandable I/O 3 Channel 3001 status information 322501
| |
Channel 3050 status information 322550
Channel 3101 status information 322551
| |
Channel 3150 status information 322600
Channel 3201 status information 322601
|
Channel 3250 status information 322650
Channel 3301 status information 322651
| |
Channel 3350 status information 322700
Channel 3401 status information 322701
| |
Channel 3450 status information 322750
Channel 3501 status information 322751
| |
Channel 3550 status information 322800
Expandable I/O 4 Channel 4001 status information 327501
| |
Channel 4050 status information 327550
Channel 4101 status information 327551
| |
Channel 4150 status information 327600
Channel 4201 status information 327601
| |
Channel 4250 status information 327650
Channel 4301 status information 327651
| |
Channel 4350 status information 327700
Channel 4401 status information 327701
| |
Channel 4450 status information 327750
Channel 4501 status information 327751
| |
Channel 4550 status information 327800
Expandable I/O 5 Channel 5001 status information 332501
| |
Channel 5050 status information 332550
Channel 5101 status information 332551
| |
Channel 5150 status information 332600
Channel 5201 status information 332601
| |
Channel 5250 status information 332650
Continued on next page
4.5 Modbus Function and Register Assignments
