YOKOGAWA GX20 User Manual

5-27
IM 04L51B01-01EN
Maintenance and Troubleshooting
1
2
3
4
5
App
Index
Code Message Description, Corrective Action, Ref. Section
516 Some items not set. Check the error log.
517 Media is read-only. Make it writable.
518 Scale image not loaded. Load a scale image.
519 Template file not loaded. Load a template file.
532 No data available. This error occurs when there is no valid data in the
internal memory. Specify valid data.
536 No data after the date and time. Select an earlier time.
537 The specified screen cannot be displayed Specify a valid screen.
539 No selected data. This error occurs when there is no valid data in the
internal memory. Specify valid data.
541 Printer not connected. Check the printer settings. Check the printer and
network conditions.
542 Printer busy. Execute after printing is complete.
551 Module was detached. Check that the module is installed correctly.
552 Detected newer version module. Check the module version.
553 Unrecognized module. Check that the module is installed correctly.
If the same message continues to appear even
after you perform the procedure above, servicing is
required. Contact your nearest YOKOGAWA dealer
for repairs.
554 Fatal module error.
555 Non-calibrated module. Perform A/D calibration.
556 RJC error module. Servicing is required. Contact your nearest
YOKOGAWA dealer for repairs.
557 A/D error module.
558 Activation required for attached modules. Activate modules.
561 Module was detached.
Please readjust reminder settings.
Check that the module is installed correctly.
562 Detected pulse counter error modules. Check that the module is installed correctly.
If the same message continues to appear even
after you perform the procedure above, servicing is
required. Contact your nearest YOKOGAWA dealer
for repairs.
570 The specified file does not exist. Specify a valid file name.
571 The specified folder does not exist. Check the folder name.
572 Deletion of the file went wrong. Change the storage medium.
573 Deletion of the folder went wrong. Change the storage medium.
581 Specified custom display file does not exist. Download the custom display file.
582 Invalid custom display file. The custom display file may be corrupt. Download
the file again.
583 Image file does not exist. Download the custom display file.
591 Certification saving error, memory full. Delete the certificate, and then save it again.
592 Key is broken. Please generate key. Create a key if you need encryption or electronic
signature.
601 Error, already signed in. You cannot change a file that has already been
signed or overwrite a signature.
604 This file is not allowed to sign record. Log in using a user account that has permission to
use signatures, and then sign.
606 Request denied, busy while signing in data. Signature information is being written to the file. Wait
until writing is finished.
607 Insufficient information to sign in. Because not all the data in the target file can be
viewed on the GX/GP, the file cannot be signed. Sign
using Universal Viewer.
611 System rebooted due to FPGA software error. An FPGA (Field Programmable Gate Array) software
error was detected. To prevent erroneous operation,
the system was restarted.
If the system does not recover, contact your nearest
YOKOGAWA dealer.
5.2 Troubleshooting
