All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L52B01-01EN June. 14, 2017-00
StandardAccessories
Product Qty
SDmemorycard(1GB) 1
Stylus pen (touch pen) 1
Tagsheet(forGP10orGP20) 1
Sheet(paper)(forGP10orGP20) 1
Power cord 1*
Dummycover(Foremptyslots)
-
* ExceptGP10powersupplysufxcode:2
ApplicationSoftware (SoldSeparately)
Model Description OS
DXA170 DAQStudiosoftware Windows7/8/8.1/10
GA10 DataLoggingSoftware Windows7/8.1/10
WindowsServer
2008/2012/2016
 OptionalAccessories(SoldSeparately)
Product Model/partno.
ModelSDmemorycard(1GB) 773001
Stylus pen (touch pen) B8740BZ
ShuntresisterforM3terminal(250Ω±0.1%)
415940
ShuntresisterforM3terminal(100Ω±0.1%)
415941
ShuntresisterforM3terminal(10Ω±0.1%)
415942
ShuntresisterforClampterminal(250Ω±0.1%)
438920
ShuntresisterforClampterminal(100Ω±0.1%)
438921
ShuntresisterforClampterminal(10Ω±0.1%)
438922
Dummycover B8740CZ
ValidationDocuments(For/ASoption)*1 773230
*1 ProvisionofValidationDocuments
A license sheet containing the license key
requiredforinstallationisprovided.
 Downloadthevalidationdocumentfromthe
followingURL.
 http://www.smartdacplus.com/software/en/
Analoginput/outputmodule,DigitalI/Omodule(soldseparately):
MODELandSUFFIXCode(GX90XA)
MODELandSUFFIXCode(GX90XD)
MODELandSUFFIXCode(GX90YD)
MODELandSUFFIXCode(GX90WD)
MODELandSUFFIXCode(GX90XP)
MODELandSUFFIXCode(GX90YA)
MODELandSUFFIXCode(GX90UT)
 PleaseseeGX90XA/GX90XD/GX90YD/GX90WD/GX90XP/GX90YAInput/OutputModuleGeneralSpecication
(GS04L53B01-01EN.)andPIDControlModule(GS04L53B01-31EN)
When connecting the Expandable I/O
 PleaseseeGX60ExpandableI/O,GX90EXExpansionModuleGeneralSpecication(GS04L53B00-01EN.)
