12
All Rights Reserved. Copyright © 2014, Yokogawa Electric Corporation
GS 04L53B01-01EN May. 19, 2017-00
 4-wireRTD/resistance
No. Symbol No. Symbol
201 CH2(I) 101 CH1(I)
202 CH2(A) 102 CH1(A)
203 CH2(B) 103 CH1(B)
204 CH2(C) 104 CH1(C)
205 Not Used 105 Not Used
206 CH4(I) 106 CH3(I)
207 CH4(A) 107 CH3(A)
208 CH4(B) 108 CH3(B)
209 CH4(C) 109 CH3(C)
210 Not Used 110 Not Used
211 CH6(I) 111 CH5(I)
212 CH6(A) 112 CH5(A)
213 CH6(B) 113 CH5(B)
214 CH6(C) 114 CH5(C)
215 Not Used 115 Not Used
A/D Calibration Value
 TwotypesofA/Dcalibrationvalues(factory
shipmentsettingandusersetting)canbesaved.
If the user setting is not proper, it can be restored
tothecalibrationvalueatfactoryshipment.
Clamp terminal
 Universal,Lowwithstandvoltagerelay,
Electromagneticrelay,Current(mA)inputtype
No. Symbol No. Symbol
201 CH2(+/A) 101 CH1(+/A)
202 CH2(-/B) 102 CH1(-/B)
203 CH2(/b)*1 103 CH1(/b)*1
204 CH4(+/A) 104 CH3(+/A)
205 CH4(-/B) 105 CH3(-/B)
206 CH4(/b)*1 106 CH3(/b)*1
207 CH6(+/A) 107 CH5(+/A)
208 CH6(-/B) 108 CH5(-/B)
209 CH6(/b)*1 109 CH5(/b)*1
210 CH8(+/A) 110 CH7(+/A)
211 CH8(-/B) 111 CH7(-/B)
212 CH8(/b)*1 112 CH7(/b)*1
213 CH10(+/A) 113 CH9(+/A)
214 CH10(-/B) 114 CH9(-/B)
215 CH10(/b)
*1
115 CH9(/b)*1
*1 Therearenosymbolindicationsforthe
electromagneticrelaytype,current(mA)input
type,orlowwithstandvoltagerelaytype.
* RTDinputterminalbisshortedinternallyacross
all channels.
 High-speeduniversaltype
No. Symbol No. Symbol
201 CH1(+/B) 101 Not Used
202 CH1(-/b) 102 Not Used
203 CH1(/A) 103 Not Used
204 Not Used 104 Not Used
205 CH2(+/B) 105 Not Used
206 CH2(-/b) 106 Not Used
207 CH2(/A) 107 Not Used
208 Not Used 108 Not Used
209 CH3(+/B) 109 Not Used
210 CH3(-/b) 110 Not Used
211 CH3(/A) 111 Not Used
212 Not Used 112 Not Used
213 CH4(+/B) 113 Not Used
214 CH4(-/b) 114 Not Used
215 CH4(/A) 115 Not Used
To Next Page
