13
All Rights Reserved. Copyright © 2014, Yokogawa Electric Corporation
GS 04L53B01-01EN May. 19, 2017-00
External Dimensions
M3 screw terminal
107.1(4.22)26
(1.02)92(3.62)
100(3.94)
3(0.12)
45.2(1.78)
43.8(1.72)
(approx. inch)
Clamp terminal
107.1(4.22)26
(1.02)
92(3.62)
100(3.94)
3(0.12)
8(0.31)
(0.07)
1.9
45.2(1.78)
43.8(1.72)
Unit: mm
(approx. inch)
Normal Operating Conditions
Fornormaloperatingconditionsofthismodule,
pleaserefertotheGeneralSpecicationsofthe
device(GX/GP,I/OBaseUnit,orGM)thatthis
moduleismounted.
GXSpecications:GS04L51B01-01EN
GPSpecications;GS04L52B01-01EN
I/OBaseUnit(ExpandableI/O)Specications:GS
04L53B00-01EN
GMSpecications:GS04L55B01-01EN
Transport and Storage Conditions
• Ambienttemperature:–25to70°C
• Ambienthumidity:5to95%RH(no
condensation)
• Vibration:10to60Hz,4.9m/s
2
maximum
• Shock:392m/s
2
maximum(inpackaged
condition)
Effects of Operating Conditions
Integraltime16.67msormoreorscaninterval50ms
ormore(forthehigh-speeduniversaltype)
• Inuenceofambienttemperature:variation
againstachangeof10°Catanaccumulation
timeof16.67msormore±(0.05%ofrdg+
0.05%ofrange)orbelow.
(Incaseofcurrent(mA)inputtype,±(0.075%of
rdg+0.05%ofrange)orbelow.)
 KpvsAu7Fe,PR20-40:±(0.05%ofrdg+0.1%)
orbelow,Cu10Ωsystemorless:±(0.2%ofrdg+
0.1°C)orbelow
No reference contact accuracy is guaranteed.
• Inuenceofpowersupplyvoltagevariation:
Accuracyissatisedintherangeofratedpower
supplyvoltage.
• Inuenceofexternalmagneticeld:Variations
againstanACexternalmagneticeld(50/60Hz,
400A/m)are±(0.1%ofrdg+0.1%)orbelow.
Installation limitations
Ifyouwanttousetheelectromagneticrelaytypeor
high-speeduniversaltypemodulesonaGM10
singleunit,uptoeightmodulescanbeinstalled.
To Next Page
