YOKOGAWA GX20 User Manual

14
All Rights Reserved. Copyright © 2014, Yokogawa Electric Corporation
GS 04L53B01-01EN May. 19, 2017-00
Safety and EMC Standards
• CSA:
CAN/CSA22.2 No.61010-1, installation category
II
*1
, pollution degree 2
*2
CAN/CSA-IEC61010-2-201
*4
• UL:
 UL61010-1(CSANRTL/C)
 UL61010-2-201(CSANRTL/C)
*4
• CE/EMCdirective
*3
:
 EN61326-1compliance,ClassATable2
 EN61000-3-2compliance
 EN61000-3-3compliance
EN55011 Class A Group 1
• CE/Lowvoltagedirective
EN61010-1
Installation category II
*1
Pollution degree 2
*2
 Notincludedinthemeasurementcategory
 EN61010-2-201compliance
*4
• EMCRegulatoryArrangementinAustraliaand
NewZealand(RCM):EN55011compliance,
Class A Group 1
• KCmarking:Electromagneticwaveinterference
preventionstandard,electromagneticwave
protectionstandardcompliance
*1 Installationcategory(overvoltagecategory)II:
Describesanumberwhichdenesatransient
overvoltagecondition.
 Impliestheregulationforimpulsewithstand
voltage.
 “II”appliestoelectricalequipmentwhich
issuppliedfromthexedinstallationlikea
distribution board.
*2 Pollution degree 2:
 Describesthedegreetowhichasolid,liquid,
or gas which deteriorates dielectric strength or
surfaceresistivityisadhering.
 “2”appliestonormalindooratmosphere.
Normally,onlynon-conductivepollutionoccurs.
*3 TheCEstandardsformodulesrepresent
standardsthataremetwhenthemoduleis
installedinthemainunit.
*4 Thisproductisdesignedasopenequipment
undertherelevantstandard,installitasfollows:
 •TheGX10/GX20isdesignedtobeinstalledinan
instrumentationpanel.
Install it in a location where people cannot touch
theterminalscarelessly.
 •TomaketheGP10/GP20complywiththe
relevantstandard,supportthepartsofthedevice
other than the front-panel control area with an
instrumentationpanelorthelike,andinstallitina
locationwherepeoplecannottouchtheterminals
carelessly or in a panel.
 •InstalltheGX60/GMunitinapanelwithadoor.
 •Theinstrumentationpanelorpanelusedfor
supportmustcomplywithCSA/UL/EN61010-
2-201ormustbeatleastIP1X(degreesof
protection)andatleastIK09.
• WEEEDirective:Compliant
DIGITAL INPUT MODULE (Model
GX90XD or GX/GP main unit
options /CRx1)
GX90XD
• Application:Remotecontrolinput,pulseinput
*1
,
etc
• Numberofinputs:16
• inputtype:DI,pulse
*1
• Measurementinterval:100ms(shortest)
• Inputtype:OpencollectororVoltage-freecontact
• Insulationtype:Photocoupler,Trance(power
supply)
• Contactrating:12VDC,20mAormore
• Inputresistance:Approx.1kΩ
• Allowableinputvoltage:+10V
• ON/OFFdetection
Open collector contact input:
VoltageinONstate:0.5VDCorless
LeakagecurrentinOFFstate:0.5mAorless
 Voltage-freecontactinput:
ContactresistanceinONstate:200Ωorless
ContactresistanceinOFFstate:50kΩor
more
• Numberofcommon:2(1point/8channels)
• Terminaltype:M3screwterminalorClamp
terminal
(IncaseofOptions/CRx1,adigitalinputmodule
hasM3screwterminals.)
• Withstandvoltage
 Betweentheinputterminalsandtheinternal
circuit:1500VACforoneminute
• Insulationresistance:
Betweentheinputterminalsandtheinternal
circuit:20MΩorgreaterat500VDC
[Pulseinputspecications]
*1
• Countingsystem:Therisingedgeofthepulseis
counted.
 Opencollector:Thesignallevelattheinput
terminalchangesfromhighto
low.
 Voltage-freecontact:Thecontactchangesfrom
open to close.
• Max.pulseperiod:
  250Hz(Thechatteringlter:Off)
  125Hz(Thechatteringlter:On)
• Min.detectionpulsewidth:Low(close),High
(open),bothis2msormore
• Pulsedetectionperiod:1ms
• Pulsemeasuringaccuracy:±1pulse
• Pulsecountinterval:mesurementinterval
• Filter:ThechatteringltercanbeswitchedOn/
Off *.
*Whenthechatteringlterisoff,connectGX/GP/GMso
that it is not affected by the noise.
*1 MATHfunction(optionalcode/MT)isrequired.
