MeasuringRange/Accuracy
1
Inputtype Range Measurementrange Measurementaccuracy(digitaldisplay) Digitaldisplay
highestreso-
lution
DC voltage 20 mV -20.000 to 20.000 mV ±(0.05%ofrdg+12μV) 1μV
60 mV -60.00 to 60.00 mV ±(0.05%ofrdg+0.02mV) 10μV
200 mV -200.00 to 200.00 mV ±(0.05%ofrdg+0.03mV) 10μV
1 V -1.0000 to 1.0000 V ±(0.05%ofrdg+0.2mV) 100μV
2 V -2.0000 to 2.0000 V ±(0.05%ofrdg+1.2mV) 100μV
6 V -6.000 to 6.000 V ±(0.05%ofrdg+2mV) 1 mV
20 V -20.000 to 20.000 V ±(0.05%ofrdg+3mV) 1 mV
50 V -50.00 to 50.00 V ±(0.05%ofrdg+0.02V) 10 mV
Standard signal 0.4-2V 0.3200 to 2.0800 V ±(0.05%ofrdg+1.2mV) 100μV
1-5V 0.800 to 5.200 V ±(0.05%ofrdg+2mV) 1 mV
Thermocouple
(does not
include
reference
junction
compensation
accuracy)
R
2
0.0 to 1760.0°C ±(0.05%ofrdg+1.0°C)
ExceptRandS;0.0to800.0°C:±1.4°C
B;400.0to800.0°C:±3.0°C
Accuracynotguaranteedfortemperatureslessthan400.0°C
0.1°C
S
2
0.0 to 1760.0°C
B
2
0.0 to 1820.0°C
K
2
-270.0 to 1370.0°C ±(0.05%ofrdg+0.7°C)
Except-200.0to0.0°C:±(0.2%ofrdg+0.7°C)
Accuracynotguaranteedfortemperatureslessthan-200.0°C
0.1°C
-200.0 to 500.0°C
E
2
-270.0 to 800.0°C ±(0.05%ofrdg+0.5°C)
Except-200.0to0.0°C:±(0.2%ofrdg++0.5°C)
Accuracynotguaranteedfortemperatureslessthan-200.0°C
0.1°C
J
2
-200.0 to 1100.0°C
T
2
-270.0 to 400.0°C ±(0.05%ofrdg+0.5°C)
Except-200.0to0.0°C:±(0.2%ofrdg++0.5°C)
Accuracynotguaranteedfortemperatureslessthan-200.0°C
0.1°C
N
2
-270.0 to 1300.0°C ±(0.05%ofrdg+0.7°C)
Except-200.0to0.0°C:±(0.5%ofrdg+0.7°C)
Accuracynotguaranteedfortemperatureslessthan-200.0°C
0.1°C
W
3
0.0 to 2315.0°C ±(0.05%ofrdg+1.0°C)
1000.0°Cormore:±0.15%ofrdg
0.1°C
L
4
-200.0 to 900.0°C ±(0.05%ofrdg+0.5°C)
Lessthan0.0°C:±(0.25%ofrdg+0.5°C)
0.1°C
U
4
-200.0 to 400.0°C ±(0.05%ofrdg+0.5°C)
Lessthan0.0°C:±(0.5%ofrdg+0.5°C)
0.1°C
Thermocouple
(does not
include
reference
junction
compensation
accuracy)
WRe3-25
5
0.0 to 2320.0°C ±(0.05%ofrdg+2.0°C)
2000.0°Cormore:±0.15%ofrdg
0.1°C
KpvsAu7Fe
6
0.0 to 300.0 K ±(0.05%ofrdg+2.0K) 0.1 K
PLATINEL II
6
0.0 to 1395.0°C ±(0.05%ofrdg+1.0°C) 0.1°C
PR20-40
7
0.0 to 1900.0°C ±(0.05%ofrdg+5.5°C)
Accuracynotguaranteedfortemperatureslessthan800.0°C
0.1°C
NiNiMo
6
0.0 to 1310.0°C ±(0.05%ofrdg+0.7°C) 0.1°C
W/WRe26
8
0.0 to 2320.0°C ±(0.05%ofrdg+2.0°C)
Accuracynotguaranteedfortemperatureslessthan300.0°C
0.1°C
N(AWG14)
9
0.0 to 1300.0°C ±(0.05%ofrdg+0.7°C) 0.1°C
XK GOST
10
-200.0 to 600.0°C ±(0.05%ofrdg+0.5°C)
Lessthan0.0°C:±(0.2%ofrdg+0.5°C)
0.1°C
RTD
(measurement
current 1 mA)
Pt100
11
-200.0 to 850.0°C ±(0.05%ofrdg+0.3°C) 0.1°C
-150.00 to 150.00°C 0.01°C
JPt100
11
-200.0 to 550.0°C 0.1°C
-150.00 to 150.00°C 0.01°C
Cu100at0°C
α=0.00425
-50.0 to 150.0°C ±(0.05%ofrdg+0.3°C) 0.1°C
Cu25at0°C
α=0.00425
-200.0 to 300.0°C ±(0.1%ofrdg+0.8°C) 0.1°C
Cu53at0°C
α=0.00426035
-50.0 to 150.0°C ±(0.05%ofrdg+0.6°C) 0.1°C
J263B
17
0.0 to 300.0 K ±0.4 K
Lessthan40.0K:±0.8K
0.1 K
Pt25
18
-200.0 to 550.0°C ±(0.1%ofrdg+0.8°C) 0.1°C
Ni100 (SAMA) -200.0 to 250.0°C ±(0.05%ofrdg+0.3°C) 0.1°C
Ni100 (DIN)
12
-60.0 to 180.0°C
Ni120
13
-70.0 to 200.0°C
Pt50
14
-200.0 to 550.0°C ±(0.05%ofrdg+0.6°C) 0.1°C
Pt200 WEED -100.0 to 250.0°C ±(0.05%ofrdg+1.0°C)
Cu100 GOST
15
-200.0 to 200.0°C ±(0.05%ofrdg+0.3°C) 0.1°C
Pt46 GOST
16
-200.0 to 550.0°C ±(0.05%ofrdg+0.6°C) 0.1°C
Pt100 GOST
15
-200.0 to 600.0°C ±(0.05%ofrdg+0.3°C) 0.1°C
rdg: reading
