GS 04L53B01-31EN
4
All Rights Reserved. Copyright © 2017, Yokogawa Electric Corporation 2017.06.26-00
Continued
Inputtype Range Measurementrange Measurementaccuracy(digitaldisplay) Digitaldisplay
highestreso-
lution
RTD
(measurement
current 1.6mA)
Cu10 GE -200.0 to 300.0°C ±(0.1%ofrdg+2.0°C)
Guaranteed accuracy range
Cu10GE:-70.0to170.0°C
Cu10L&N:-75.0to150.0°C
Cu10WEED:-200.0to260.0°C
Otherthanabove:-200.0to300.0°C
0.1°C
Cu10 L&N -200.0 to 300.0°C
Cu10 WEED -200.0 to 300.0°C
Cu10 BAILEY -200.0 to 300.0°C
Cu10at20°C
α=0.00392
-200.0 to 300.0°C
Cu10at20°C
α=0.00393
-200.0 to 300.0°C
Cu10 GOST
19
-200.0 to 200.0°C ±(0.1%ofrdg+2.0°C) 0.1°C
Cu50 GOST
16
-200.0 to 200.0°C ±(0.05%ofrdg+0.6°C) 0.1°C
DI Level Thresholdlevel(Vth=2.4V)accuracy±0.1V -
Contact
20
100Ωorless:1(ON),10kΩormore:0(OFF) -
rdg: reading
1 Understandardoperatingconditions:23±2ºC,55±10%RH,supplyvoltage90–132,180–264VAC,supplyfrequencywithin50/60Hz
±1%,warm-upof30minutesormore,novibrationsorotherhindrancestoperformance.
2 R, S, B, K, E, J, T, N: IEC 60584-1, DIN EN 60584, JIS1602
3 W:W-5%Re/W-26%Re(HoskinsMfg.Co.)ASTME988-96
4
L: Fe-CuNi, DIN43710, U: Cu-CuNi, DIN43710
5 WRe3-25:W-3%Re/W-25%Re(HoskinsMfg.Co.)ASTME988-96
6
KpvsAu7Fe, PLATINEL II, NiNiMo: ASTM E1751
7 PR20-40:PtRH20%-PtRh40%(JohnsonMattheyPlc)ASTM
E1751
8 W/WRe26:W/W-26%Re(HoskinsMfg.Co.)ASTME1751
9 N(AWG14): NBS
10 XK GOST: Type L (GOST R 8.525-2001)
11 Pt100: JIS C 1604, IEC 60751, DIN EN 60751
JPt100: JIS C1604, JIS C1606
12 Ni100 (DIN): DIN 43760
13 Ni120: McGRAW EDISON COMPANY
14 Pt50: JIS C1604, JIS C1606
15 Cu100 GOST, Pt100 GOST: GOST 6651-2009
16 Cu50 GOST, Pt46 GOST: GOST 6651-94
17 J263B:YOKOGAWAJ263*B
18 Pt25:1/4theJPt100resistance
19 Cu10GOST:1/10theCu100GOSTresistance
20 Detectedcurrentvalue:approx.10μA
Measuringaccuracywhenscaling:
Measuringaccuracywhenscaling(digits)=measuringaccuracy(digits)×scalingspan(digits)/measurementspan(digits)+2digits
*Fractionsroundedup
