SECTION 6 - I/O BOARD
FORM 160.54-M1
ISSUE DA
TE: 10/25/2019
JOHNSON CONTROLS
JCI COMP
ANY CONFIDENTIAL
6
FIGURE 35 -
I/O BOARD TYPICAL
OPTOCOUPLER CIRCUIT
OPTO-COUPLER
TYPICAL
(20 CKTS)
+5VDC
J19 - 21
JI - Y
JI - 22/23
NEUTRAL
TB3 - 2
TB4 - X
TB3 - X
LD04057
FIGURE 36 -
I/O BOARD TYPICAL
FIELD CONNECTIONS
11
5V
AC
TB3 - 1
TB4 - 1
TB4 - X
OP
TO
-
COUPLER
J1 -
Y
FIELD SUPPLIED
DR
Y
CONT
ACTS
(R
AT
ED 5MA @ 1
15V
AC)
LD04058
102
104
