256

FORM 160.54-M1

ISSUE DATE: 10/25/2019

SECTION 31 - HEAT PUMP DUTY

JCI COMPANY CONFIDENTIAL JOHNSON CONTROLS

FIGURE 97 - HEAT PUMP DUTY BLOCK DIAGRAM

NOTES:

1. Requires program jumper JP21 positioned on pins 2 and 3 with leaving chilled thermistor connected to J7 as shown.

2. 0 to 10 VDC or 2 to 10 VDC input = J22-3

0 to 20mA or 4 to 20 MA input = J22-4

3. Input resets Leaving Chilled Setpoint when heat pump operational mode setpoint is set to "Cooling"

Input resets Leaving Condenser Setpoint when heat pump operational mode setpoint are set to "Heating".

LEAVING CONDENSER

WATER THERMISTOR

LEAVING CHILLED

WATER THERMISTOR

REMOTE LEAVING

CHILLED CONDENSER

WATER SETPOINT

MICRO BOARD

031-02430-001

031-03630-001

6IN

16 +5VDC

14 IN

15 +5VDC

NOTE 2

5 GND

(NOTE 1)

J22

OPEN

J19

I/O BOARD

031-01743-002

PRE - ROTATION

VANES

ACTUATOR

TB1

LD15439
