York OPTIVIEW YK - FIGURE 66 - Proximity Probe Interface - Probe Part Number 025-30961-000; FIGURE 67 - Proximity Probe Interface - Probe Part Number 025-35900-000 and 025-35900-001

160
FORM 160.54-M1
ISSUE DATE: 10/25/2019
SECTION 15 - PROXIMITY PROBE
JCI COMPANY CONFIDENTIAL JOHNSON CONTROLS
+24VDC
POWER
SUPPLY
NOTE 2
JX
2
MICRO
BOARD
+24VDC
NOTE 1
2
1
J1
J9
J8
12
2
1
15
12
PROXIMITY / TEMP PROBE
+5VDC (DRAIN LINE TEMP)
GND
DRAIN TEMP
PROXIMITY
GND
+5VDC
+24VDC
J31 P31
1
2
1
2
NOTES:
1. +24 VDC Reference for “Proximity probe - Low Supply Voltage” Cycling Shutdown.
2. CM-2 Board, Solid State Starter Logic Board or Adaptive Capacity Control Board as determined by the Starter Application.
FIGURE 66 - PROXIMITY PROBE INTERFACE – PROBE PART NUMBER 025-30961-000
LD04090
LD05532C
NOTES:
1. +24 VDC Reference for “Proximity probe - Low Supply Voltage” Cycling Shutdown.
2. CM-2 Board, Solid State Starter Logic Board or Adaptive Capacity Control Board as determined by the Starter Application.
FIGURE 67 - PROXIMITY PROBE INTERFACE – PROBE PART NUMBER 025-35900-000 AND 025-35900-001
+24VDC
POWER
SUPPLY
NOTE 2
JX
2
MICRO
BOARD
+24VDC
NOTE 1
2
1
J1
J9
J8
12
16
15
12
PROXIMITY PROBE
+5VDC
GND
PROXIMITY
GND
+5VDC
+24VDC
J31 P31
1
2
1
2
