SECTION 15 - PROXIMITY PROBE
FORM 160.54-M1
ISSUE DATE: 10/25/2019
JOHNSON CONTROLS JCI COMPANY CONFIDENTIAL
15
TABLE 12 - PROXIMITY PROBES
PART NUMBER SUPPLY VOLTAGE DESCRIPTION
025-30961-000 +24 VDC, +5 VDC
Production until April 2000. Senses Proximity. Also senses High Speed
Drain Line Oil Temperature unless equipped with Flash memory card
version C.MLM.01.03 or later. 1-piece integrated design that includes
the electronics in the barrel of the probe. See Figure 66 on page 160.
025-35900-000 +24 VDC, +5 VDC
Production from April 2000 until March 2003. Senses Proximity only.
Does not sense High Speed Drain Temperature. Supersedes probe
025-30961-000. 1-piece integrated design that includes the electron-
ics in the barrel of the probe. See Figure 67 on page 160.
025-35900-001 +24 VDC, +5 VDC
Production from March 2003 until March 2006. Senses proximity only.
Does not sense High Speed Drain Temperature. Supersedes probe
025-35900-000. 1-piece integrated design that includes the electron-
ics in the barrel of the probe. See Figure 67 on page 160.
025-40496-000 +24V
Production after March 2006. Supersedes all previous probes. Sens-
es proximity only. Does not sense High Speed Drain Temperature.
This probe assembly is a 2-piece design that has the electronics in a
module that is separate from the probe. This design allows the elec-
tronics portion of the probe to be replaced separately, thus eliminating
the need to evacuate the chiller refrigerant charge when replacing
only the electronics portion of the probe. The probe is connected to
the electronics module with a coaxial cable. See Figure 68 on page
161 for parts breakout of probe assembly 025-40496-000.
