71
SECTION 4 - MICROBOARD 031-02430-000
AND 031-02430-001
FORM 160.54-M1
ISSUE DA
TE: 10/25/2019
JOHNSON CONTROLS
JCI COMP
ANY CONFIDENTIAL
4
FIGURE 23 -
CONFIGURABLE
ANALOG
AND REMOTE SETPOINT INPUTS (HEA
T
PUMP DUT
Y)
LD15436
NOTE:
1.
Program Jumper JP21 must be positioned on pins 2-3.
REMOTE CURRENT
LIMIT SETPOINT
REMOTE LEA
VING
CHILLED LIQUID
TEMP SETPOINT
REMOTE SETPOINT
GND CONNECTIONS
0-10 VDC /
2-10 VDC
0-20 mA
/
4-20 mA
5
4
3
1
2
16
4
14
2
13
15
MUX
47K
JP21
JP22
JP23
JP24
200
7.5 K
1
2
3
1
2
3
1
2
3
1
2
3
71.5 K
+5V
3
17
+5V
J7
J22
0-10 VDC /
2-10 VDC
0-20 mA
/
4-20 mA
LEA
VING CHILLED
LIQUID TEMPRERA
TURE
THERMISTOR
See Note 1
70
72
