SECTION 23 - HOT GAS BYPASS

JCI COMPANY CONFIDENTIAL JOHNSON CONTROLS

FIGURE 80 - INTERFACE, HOT GAS BYPASS (I/O BOARD 031-02895-000)

MICROBOARD

031-02430-000

031-02430-001

I/O

BOARD

031-02895-000

EVAPORATOR

TRANSDUCER

CONDENSER

TRANSDUCER

HOT GAS BYPASS

CONTROL VALVE

0-10VDC

RS-485

COM 3

VANE

POSITION

EVAP PRESSURE

COND PRESSURE

J12

22 10 11

18 21

4/12

3/11

(-)

(+)

TB1

VALVE

POSITIONING

SERIAL

COMMS

AO1

GND

OPEN

NOTES:

1. If chiller is equipped with a Compressor Motor Variable Speed Drive, the PRV

potentiometer is connected to either the Adaptive Capacity Control Board (J4)

or the microboard J7, depending on where the ACC function is performed.

Refer to explanation in this section.

LD14240
