ZCS AZZURRO HYD6000 - Wall Installation Position

User’s Manual 1PH HYD3000-HYD6000-ZSS
Rev. 1.1 16/03/2021
Identification: MD-AL-GI-00
Rev. 1.1 of 16/03/2021 - Application: GID
14/94
10
ESD gloves
Must be worn by operators
11
Safety goggles
Must be worn by operators
12
Dust mask
Must be worn by operators
3.5. Wall installation position
The 1PH HYD3000-HYD6000-ZSS inverter must be mounted vertically (to ensure rapid heat dissipation). Install
the 1PH HYD3000-HYD6000-ZSS inverter in a location protected from direct sunlight and from possible snow
accumulation. Ensure that the installation position is well ventilated.
Figure 4 – Installation position of the 1PH HYD3000-HYD6000-ZSS inverter
