User’s Manual 1PH HYD3000-HYD6000-ZSS
Rev. 1.1 16/03/2021
Identification: MD-AL-GI-00
Rev. 1.1 of 16/03/2021 - Application: GID
- Check that the router has access to the network and that the connection is stable; check that a PC can
access the Internet
Check that port 80 of the router is open and enabled to send data.
It is advisable to check the brand and model of the home router you are trying to connect to the
Ethernet adapter; some router brands may have closed communication ports. In this case, contact the
customer service of the router’s manufacturer and ask them to open port 80 (direct from the network
to external users).
11.3. 4G adapter
The ZCS 4G adapters are sold with a virtual SIM integrated into the device with data traffic fee included for10
years, which is adequate for the proper transmission of data to monitor the inverter.
In order to monitor the inverter, the RS485 communication address must be set to 01 directly from the
display.
11.3.1. Installation
Installation must be carried out for all inverters compatible with the adapter. However, the procedure is
quicker and easier as there is no need to open the front cover of the inverter.
Installation tools:
Cross screwdriver
4G adapter
4) Switch off the inverter following the procedure described in this manual.
5) Remove the cover for accessing the Wi-Fi/ GPRS connector on the bottom of the inverter by unscrewing
the two cross-head screws (a), or by unscrewing the cover (b), depending on the inverter model, as
shown in the figure.
