11.2. Ethernet adapter
11.2.1. Installation
Installation must be carried out for all inverters compatible with the adapter. However, the procedure is
quicker and easier as there is no need to open the front cover of the inverter.
Proper operation of the device requires the presence of a modem correctly connected to the network and in
operation in order to achieve stable data transmission from the inverter to the server.
In order to monitor the inverter, the RS485 communication address must be set to 01 directly from the
display.
Installation tools:
 Cross screwdriver
 Ethernet adapter
 Shielded network (Cat. 5 or Cat. 6) crimped with RJ45 connectors
1) Switch off the inverter following the procedure described in this manual.
2) Remove the cover for accessing the Wi-Fi/Eth connector on the bottom of the inverter by unscrewing the
two cross-head screws (a), or by unscrewing the cover (b), depending on the inverter model, as shown in
the figure.
(a)
(b)
Figure 65 – Port of the Ethernet adapter
