ZCS AZZURRO HYD6000 - Basic Settings Configuration

User’s Manual 1PH HYD3000-HYD6000-ZSS
Rev. 1.1 16/03/2021
Identification: MD-AL-GI-00
Rev. 1.1 of 16/03/2021 - Application: GID
40/94
In the main interface, press the “Up” button to enter the page with the photovoltaic settings:
Main interface
Press “OK”
1. PV1 Voltage
2. PV1 Current
3. PV1 Power
4. PV2 Voltage
5. PV2 Current
6. PV2 Power
7. Inverter Temp.
In the main interface, press “Back” to enter the main menu. The main menu has the following five options:
Main interface
Press “Back”
“Up” ↑
“Down” ↓
1. Settings
2. Advanced settings
3. Event list
4. System Info
5. SW Update
6. Prod. Statistics
6.4.1. Basic settings
1. Settings
Press “OK"
“Up”↑
“Down” ↓
1. Language
2. Date and Time
3. Working Mode
4. PV input mode
5. EPS mode
6. Communication address
7. Self-test
