Accessories
126
USB Charge/Com Snap-on Cup
The USB Charge/Com Snap-on Cup:
• Provides 5 VDC power to operate the device and to charge the battery.
• Provides power and/or communication with the host computer over USB to the device.
• Compatible with devices using the following battery:
• 7000 mAh PowerPrecision+ standard battery
Figure 103 USB Charge/Com Snap-on Cup
Connecting the USB Charge Cable to Device
To connect the USB Charge Cable to the device, insert the USB Charge Cable straight onto the device until
the device touches the bottom of the cable cup.
Pigtail with USB Socket
USB Charge/Com Snap-on Cup
NOTE: To function properly, remove the lower part of the rubber boot or the entire rubber boot before placing in a
charging cradle.
