Zebra MC9300 User Manual

Getting Started
22
15.Slide both the keypad latches toward the top of the device.
Figure 13 Slide Keypad Latches
16.Using a Torx T8 screwdriver, replace the two keypad latch screws inside the battery slot and torque to 5.8
kgf-cm or 5.0 lbf-in.
Figure 14 Replace Keypad Latch Screws
17.Press and hold the Power key to power on the device.
Backup Power
The device is equipped with a super-capacitor (supercap) to provide backup power to the device when the
main battery is removed. The supercap will retain random access memory (RAM) data in memory for
approximately five minutes after the main battery is removed during Hot Swap.
IMPORTANT: The supercap is automatically charged from the main battery and requires approximately
ten minutes to fully charge.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures, for example at approximately +37°C
(+98°F), the device or cradle may for small periods of time alternately enable and disable battery charging to
Keypad Latches
Keypad Latch Screws

Zebra MC9300 Specifications

General

Operating Temp	-4°F to 122°F / -20°C to 50°C
Processor	Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System	Android 8.1 Oreo
Display	4.3 inch WVGA (800 x 480), color display
RAM	4 GB
Storage	32 GB Flash
Connectivity	802.11 a/b/g/n/ac/d/h/i/r/k/w, Bluetooth 5.0
Camera	Optional 13 MP rear camera
Durability	IP65 and IP67 sealing
Memory	4 GB RAM/32 GB Flash
Touch Panel	Capacitive touch panel with Corning Gorilla Glass
Keypad Options	Alphanumeric, numeric and functional numeric keypads
Scanning	Integrated 1D/2D barcode scanner
Drop Specification	Multiple 8 ft. / 2.4 m drops to concrete at room temperature
Expansion Slots	MicroSD Card slot (supports up to 256 GB)
Battery	7000 mAh PowerPrecision+ Li-Ion rechargeable battery
