Zebra MC9300 User Manual

Data Capture
98
Figure 82 RS6000 Pick List Mode with Multiple Barcodes in Aiming Pattern
5. The captured data appears in the text field.
Scanning with the DS3608 USB Scanner or DS3678 Bluetooth Scanner
To scan with the DS3608 or DS3678:
1. Pair the scanner with the device. For more information, see Connecting a USB Scanner for the DS3608 or
Pairing Bluetooth Scanners for the DS3678.
2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).
3. Point the scanner at a barcode.
Figure 83 Barcode Scanning (DS3678 shown)
4. Press and hold the trigger.
Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility in
bright lighting conditions.
Figure 84 DS3608/DS3678 Aiming Pattern

Zebra MC9300 Specifications

General

Operating Temp	-4°F to 122°F / -20°C to 50°C
Processor	Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System	Android 8.1 Oreo
Display	4.3 inch WVGA (800 x 480), color display
RAM	4 GB
Storage	32 GB Flash
Connectivity	802.11 a/b/g/n/ac/d/h/i/r/k/w, Bluetooth 5.0
Camera	Optional 13 MP rear camera
Durability	IP65 and IP67 sealing
Memory	4 GB RAM/32 GB Flash
Touch Panel	Capacitive touch panel with Corning Gorilla Glass
Keypad Options	Alphanumeric, numeric and functional numeric keypads
Scanning	Integrated 1D/2D barcode scanner
Drop Specification	Multiple 8 ft. / 2.4 m drops to concrete at room temperature
Expansion Slots	MicroSD Card slot (supports up to 256 GB)
Battery	7000 mAh PowerPrecision+ Li-Ion rechargeable battery
