Zebra MC9300 User Manual

Keypads
160
Keypad Special Functions
The keypad special functions are color coded on the keypads. For example, on the 53-key keypad, the display
backlight icon is blue indicating that the blue function key must be selected first to access the display backlight.
Table 21 Keypad Special Functions
Icon
53-Key STD,
5250, and VT
Keypads
Special Function
Blue key + X Decreases the keyboard backlight
intensity.
Blue key + Y Increases the keypad backlight
intensity.
Blue key + D Increases display backlight intensity.
Blue key + I Decreases display backlight intensity.
Blue key + H Increases overall system volume.
Blue key + M Decreases overall system volume.
Blue key + CTRL Enables Alt keypad functions.
NOTE: Only applicable if the Large Key Indi-
cator is enabled.
Blue key + Space Sends TAB character (forward tab).
NOTE: Use of display and keypad backlighting can significantly reduce battery life.

Zebra MC9300 Specifications

General

Operating Temp	-4°F to 122°F / -20°C to 50°C
Processor	Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System	Android 8.1 Oreo
Display	4.3 inch WVGA (800 x 480), color display
RAM	4 GB
Storage	32 GB Flash
Connectivity	802.11 a/b/g/n/ac/d/h/i/r/k/w, Bluetooth 5.0
Camera	Optional 13 MP rear camera
Durability	IP65 and IP67 sealing
Memory	4 GB RAM/32 GB Flash
Touch Panel	Capacitive touch panel with Corning Gorilla Glass
Keypad Options	Alphanumeric, numeric and functional numeric keypads
Scanning	Integrated 1D/2D barcode scanner
Drop Specification	Multiple 8 ft. / 2.4 m drops to concrete at room temperature
Expansion Slots	MicroSD Card slot (supports up to 256 GB)
Battery	7000 mAh PowerPrecision+ Li-Ion rechargeable battery
