Zebra MC9300 User Manual

Keypads
154
53-Keys 5250 Emulator Keypad
There are two physical configurations of the 5250 emulator keypad, however both of the keypads are
functionally identical. The 5250 emulator keypad contains a Power button, application keys, scroll keys and a
function key. The keypad is color-coded to indicate the alternate function key (blue) values. Note that keypad
functions can be changed by an application so the device’s keypad may not function exactly as described. See
the Key Descriptions table for key and button details, and the Keypad Special Functions table for the keypad’s
various functions.
Figure 127 53-Keys 5250 Emulator Keypad
NOTE: The 5250 emulator configuration is only used when the device is running the 5250 emulation software.

Zebra MC9300 Specifications

General

Operating Temp	-4°F to 122°F / -20°C to 50°C
Processor	Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System	Android 8.1 Oreo
Display	4.3 inch WVGA (800 x 480), color display
RAM	4 GB
Storage	32 GB Flash
Connectivity	802.11 a/b/g/n/ac/d/h/i/r/k/w, Bluetooth 5.0
Camera	Optional 13 MP rear camera
Durability	IP65 and IP67 sealing
Memory	4 GB RAM/32 GB Flash
Touch Panel	Capacitive touch panel with Corning Gorilla Glass
Keypad Options	Alphanumeric, numeric and functional numeric keypads
Scanning	Integrated 1D/2D barcode scanner
Drop Specification	Multiple 8 ft. / 2.4 m drops to concrete at room temperature
Expansion Slots	MicroSD Card slot (supports up to 256 GB)
Battery	7000 mAh PowerPrecision+ Li-Ion rechargeable battery
