Specifications
144
Audio Speaker
Performance Characteristics
CPU Qualcomm Snapdragon ™ 660 octa-core, 2.2 GHz
Operating System Android 8.1 Oreo with Zebra’s Restricted Mode for control
over GMS and other services.
Memory 4 GB RAM/32 GB Flash pSLC.
Output Power (USB) USB: 5 VDC @ 500 mA max.
User Environment
Operating Temperature Standard: -4°F to 122°F/-20°C to +50°C
Freezer: -22°F to 122°F/-30°C to +50°C
Storage Temperature -40°F to 158°F/-40°C to 70°C
Charging Temperature 0°C to 40°C (32°F to 104°F)
Humidity Standard: 5% to 95%, non-condensing
Freezer: 5% to 95%, condensing
(Condensation-free freezer model with integrated heaters.)
Drop Specification Multiple 8ft. (2.4m) drops per MIL-STD-810G at room
temperature. Multiple 6ft. (1.8m) drops to concrete across
the operating temperature range.
Tumble Specification 2000 3.2 ft. (1m) tumbles (4000 hits); meets and exceeds
IEC tumble specifications.
Sealing IP67 and IP65 per IEC sealing specification.
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to
2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock -40°C to 70°C (-40°F to 158°F) rapid transition.
Electrostatic Discharge (ESD) +/-15kVdc air discharge
+/-8kVdc direct discharge
+/-8kVdc indirect discharge
Interactive Sensor Technology (IST)
Ambient Light Sensor Ambient light sensor used to auto adjust display and
keyboard back light brightness.
Motion Sensor 3-axis accelerometer provides motion-sensing for dynamic
screen orientation.
Wireless LAN Data Communications
Radio IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/w; Wi-Fi certified; IPv4, IPv6,
2x2 MU-MIMO
Data Rates 5GHz: 802.11a/n/ac — up to 866.7 Mbps
2.4GHz: 802.11b/g/n — up to 300 Mbps
Table 17 MC93XX Technical Specifications (Continued)
Item Description
