Getting Started
19
6. Using a Torx T8 screwdriver with a large grip, remove the two keypad assembly screws from the top of the
keypad.
Figure 6 Remove Keypad
7. Lift the keypad from the device.
8. Slide the microSD card holder to the Open position.
Figure 7 Open microSD Card Holder
microSD Card Holder
Keypad Screws
Keypad
